Name: 0.75KW 2.39N.M AC Servo Motor 80ST-M02430 With 2500PPR Encoder Resolution
Brand: Jkongmotor
SKU: 80ST-M02430
Price: 211 USD
Availability: InStock
Rating: 4.9 (135 reviews)

Home Products AC Servo Motor

0.75KW 2.39N.M AC Servo Motor 80ST-M02430 With 2500PPR Encoder Resolution

Product Details:

Place of Origin:	China
Brand Name:	Jkongmotor
Certification:	CE
Model Number:	80ST-M02430

Payment & Shipping Terms:

Minimum Order Quantity:	3
Price:	211USD/SET
Packaging Details:	CARTON
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact Now

Detailed Product Description

Weight:	2.86Kg	AmbientHumidity:	≤85%
PositioningAccuracy:	±0.02mm	ProtectionLevel:	IP65
RatedSpeed:	3000rpm	RatedVoltage:	220V
InsulationClass:	F	EncoderResolution:	2500PPR
High Light:	0.75KW AC Servo Motor , 80ST-M02430 , 2500PPR AC Servo Motor

0.75KW 2.39N.M AC Servo Motor 80ST-M02430 With 2500PPR Encoder Resolution

Product Description:

AC Servo Motor

The AC Servo Motor boasts a wide range of features, notably its rated torque of 2.39 N.m and an ambient temperature range of -20℃ to +50℃. Its insulation class is rated F and it can also withstand ambient humidity up to 85%.

This dynamic, feature-rich AC Servo Motor is designed to be reliable, efficient and powerful. It is suited for a range of applications and is the perfect choice for any project. Whether you require a motor for industrial, commercial or residential use, the AC Servo Motor can provide you with the power you need.

The AC Servo Motor is the ideal choice for any project. It offers powerful performance, efficient operation and reliable results. Its rated torque of 2.39 N.m, insulation class of F and ambient temperature range of -20℃ to +50℃ make it the perfect motor for any application, while its ability to withstand ambient humidity up to 85% ensures that it will continue to perform optimally in a range of environments.

Features:

Product Name: AC Servo Motor
Positioning Accuracy: ±0.02mm
Ambient Humidity: ≤85%
Ambient Temperature: -20℃~+50℃
Motor Type: AC Servo Motor
Control Mode: Pulse+Direction

Technical Parameters:

Parameter	Value
Motor Type	AC Servo Motor
Rated Speed	3000rpm
Rated Voltage	220V
Weight	2.86kg
Ambient Temperature	-20℃~+50℃
Control Mode	Pulse+Direction
Insulation Class	F
Rated Torque	2.39N.m
Encoder Resolution	2500PPR
Ambient Humidity	≤85%

Applications:

AC Servo Motor – Jkongmotor 80ST-M02430
The AC Servo Motor – Jkongmotor 80ST-M02430 is the perfect solution for applications requiring precise positioning accuracy and high power. With its IP65 protection level, this servo motor is designed to be dust-proof and water resistant, allowing it to be used in a wide range of industrial and commercial environments. It is also capable of delivering up to 750W of power, and has a positioning accuracy of ±0.02mm, making it ideal for applications requiring precise control. Furthermore, it has a wide operating temperature range of -20℃~+50℃ and can handle humidity levels up to 85%. This makes the AC Servo Motor – Jkongmotor 80ST-M02430 an ideal choice for applications in factory automation, packaging and robotics, as well as other industrial and commercial uses. It is a reliable, high performance motor that can help your business achieve optimal results.

Support and Services:

AC Servo Motor Technical Support and Service

At XYZ Company, we provide technical support and service for our AC Servo Motor. Our technical support team is available to answer any questions you may have about the product, provide troubleshooting assistance, and help you get the most out of your product. Our service team is dedicated to providing fast, efficient, and reliable repairs to your AC Servo Motor.

If you need technical support or service for your AC Servo Motor, please feel free to contact us at [insert contact info]. We look forward to hearing from you and helping you get the most out of your product.
