| Place of Origin: | Jiangsu, China (Mainland) |
| Brand Name: | Jkongmotor |
| Certification: | CE, ROHS,ISO9001 |
| Model Number: | JKBLD2200 |
| Minimum Order Quantity: | 3-10pcs |
|---|---|
| Price: | US$93.5~US$97.5 |
| Packaging Details: | with export carton . big quantity with pallet |
| Delivery Time: | For samples , 7-15 days / For batch , 15-25days |
| Payment Terms: | T/T , paypal , Western Union, L/C |
| Supply Ability: | 100000pcs/month |
| Model No.: | JK110BLS Serial | Supply Voltage: | AC80V-220V, 310VDC |
|---|---|---|---|
| Current: | 0A - 10A | Weight: | 1000g |
| Certified: | CE ROHS | Matched Motor: | 0 - 2200w |
| Driver Model: | JKBLD2200 | Speed: | 100-10000rpm/min |
| Body Length: | 155mm -205mm | Application: | Agricultural Implement |
| Phase: | 3 | Motor Type: | DC Motor |
| Power: | 1kw, 1.5kw, 2kw | Color: | Black |
| Motor Shaft: | 19mm With Keyway | ||
| High Light: | 110BLS BLDC Motor,2.2kw BLDC Motor,10000rpm/Min BLDC Motor Controller |
||
2.2kw 110BLS motor BLDC Motor 100-10000rpm/min AC80V-220V 0-10A with controller JKBLD2200
Product Overview:
Main features:
Electrical Specification:
(1)Environmental Temperature:25℃
| Power supply |
AC100V～250V direct current (Capacity according to motor power selection) |
| The maximum input current |
Not greater than10A (according to motor and rated load) |
| The maximum power | The maximum is 2200W (over power motor is strictly prohibited) |
| Insulation resistance | General temperature﹥500MΩ |
| Insulation strength | General temperature and pressure 0.5KV,1minitute |
(2)EnvironmentalParameter
| Cooling method | Natural air cooling & forced air cooling | |
| Environment | Condition | Avoid dust, oil mist and corrosive gases |
| Temperature | 0℃～+50℃ | |
| Humidity | ﹤80%RH,no condensation, no frost | |
| Vibration | 5.9m/s2 max | |
| Reserved temperature | -20℃～+65℃ | |
| Size | 198mmX103mmX86mm | |
| Weight | About 1Kg | |
Note: Due to dramatic changes in the temperature of the storage environment, it is easy to form condensation or frost. In this case, the drive should be placed for 12 hours or more. Until the drive temperature and ambient temperature is consistent, it can be on power.
Terminal interface description:
| Function | Mark | Description |
| Indicator light | POWER | If the green power indicator is lighten, it shows that power is normal. |
| ALM | If the red status indicator is slow flash, it means waiting; Quick flash means operation; It always lights meaning faults or off-line; | |
| Control signal port | +5V1 | Control signal power+( inner power output ) |
| VSP |
External speed control signal Control way: By connecting with a potentiometer to change VSP, then it can complete 0 ~ 100% speed adjustment. The range is 0-5V |
|
| FG | Motor speed pulse output is measuring the frequency of this signal. Then converts it into the actual motor speed. | |
| DIR | Rotary direction is controlled by high and low electrical level, motor forward: connected with GND1, motor reversal (anticlockwise) ;without GND1 or connected with +5V, motor forward (clockwise) | |
| EN | Connected EN with GND1, motor can work(online status);without connected,motor can not work(offline status and the red light keep working) | |
|
Hall control port |
+5V2 | + motor’s Hall power |
| HU | Hall sensor signal U phase input | |
| HV | Hall sensor signal V phase input | |
| HW | Hall sensor signal W phase input | |
| GND2 | The motor’s Hall power supply | |
| The motor and power port | U,V,W | The motor’s three-phase output signal |
| AC1,AC2 | The input power is AC100V～250V |
General problems
1. How can get it started as soon as possible when you first use the drive?
After you correctly connect the power cord, the motor line, the Hall line, the external potentiometer slowly accelerates. After the motor is turned correctly, you can test the enable, direction and other functions. If you are unfamiliar with the product, the initial use should be done after the test. And then it can be installed to the actual use.
2. What will come about if power supply is reverse?
It will immediately burn the drive.
3. What is the maximum of the upper control signal voltage ?
The maximum voltage of the speed regulation signal is 5V. Exceeding this voltage will cause the drive to burn.
4. After the driver has been working for a long time, the shell is hot. Is it normal?
Yes, it is. At room temperature, after long working hours, it is up to 90 degrees. And it will not affect the performance.
5. The power indicator is light, but the motor does not turn and shift, what is the reason?
There may be a mistake in the phase line and the Hall line. Please re-energize the wiring according to the motor manual.
6. Can my motor speed transferred to 6000 with this drive?
The maximum speed of the brushless motor is determined by the parameters of the motor itself. The drive can control the motor speed from 0 to the highest speed.
7. I already have a motor and how to install this drive after wiring?
You must first determine the motor phase and the definition of the Hall line, and then you can connect it with wires. If you are not sure, you need to ask the motor manufacturers. Incorrect wiring can cause damage to the drive.
8. Can I add some features on this drive or do new product development?
Yes, please contact us.
What is a brushless DC motor?
A brushless DC motor (also known as a BLDC motor or BL motor) is an electronically commuted DC motor which does not have brushes. The controller provides pulses of current to the motor windings which control the speed and torque of the synchronous motor.
These types of motors are highly efficient in producing a large amount of torque over a vast speed range. In brushless motors, permanent magnets rotate around a fixed armature and overcome the problem of connecting current to the armature. Commutation with electronics has a large scope of capabilities and flexibility. They are known for smooth operation and holding torque when stationary.
