JKBLD70 3 Phase 10000rpm 24VDC BLDC PWM Speed Controller
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jkongmotor
Certification: CE, ROHS,ISO9001
Model Number: JKBLD70
Payment & Shipping Terms:
Minimum Order Quantity: 3-10PCS
Price: US$13~US$16
Packaging Details: with export carton . big quantity with pallet
Delivery Time: For samples , 7-15 days / For batch , 15-25days
Payment Terms: T/T , paypal , Western Union, L/C
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Model No.: JKBLD70 Supply Voltage: 12VDC ~ 24VDC
Current: 0.05A ~ 3A Weight: 600g
Certified: CE ROHS Matched Motor: 0 ~ 70w
Hall Sensor Voltage: 4.5v ~ 6.5v Color: Silver
Size: 56.5mm*96mm Environment Temperature: -10℃ ~ 50℃
High Light:

10000rpm PWM Speed Controller

,

24VDC PWM Speed Controller

,

3 Phase BLDC speed controller



Driver JKBLD70 3 phase 0-10000rpm 12-24VDC brushless dc driver PWM speed controller



Description:



The JKBLD70 is a high performance, cost-effective 3 phase BLDC motor drive which can provide power output 70VA max. The design is based on advanced current control technology and feature high torque, low noise, low vibration, over current protection, over load protection.



Products working:

  • Environment temperature : -10℃~ 50℃
  • Input voltage : +12V~+24V DC
  • Output Current: 0.05A-3A
  • Suitable motor speed : 0~10000rpm
  • Hall sensor voltage : 4.5V~6.5V
  • External Potentiometer: 10KΩ
Model
Specification Unit JK42BLS01 JK42BLS02 JK42BLS03 JK42BLS04
Number Of Phase Phase 3
Number Of Poles Poles 8
Rated Voltage VDC 24
Rated Speed Rpm 4000
Rated Torque N.m 0.0625 0.125 0.185 0.25
Rated Current Amps 1.8 3.3 4.8 6.3
Rated Power W 26 52.5 77.5 105
Peak Torque N.m 0.19 0.38 0.56 0.75
Peak Current Amps 5.4 10.6 15.5 20
Back E.M.F V/Krpm 4.1 4.2 4.3 4.3
Torque Constant N.m/A 0.039 0.04 0.041 0.041
Rotor Inertia g.c㎡ 24 48 72 96
Body Length mm 41 61 81 100
Weight Kg 0.3 0.45 0.65 0.8
Sensor Honeywell
Insulation Class B
Degree of Protection IP30
Storage Temperature -25~+70℃
Operating Temperature -15~+50℃
Working Humidity 85% RH
Working Environment Outdoor (no direct sunlight), no corrosive gas, no flammable gas, no oil mist, no dust
Altitude 1000 meters or less
