| Place of Origin: | Jiangsu, China (Mainland) |
| Brand Name: | Jkongmotor |
| Certification: | CE, ROHS,ISO9001 |
| Model Number: | JKBLD480 |
| Minimum Order Quantity: | 3-10pcs |
|---|---|
| Price: | US$26~US$30 |
| Packaging Details: | with export carton . big quantity with pallet |
| Delivery Time: | For samples , 7-15 days / For batch , 15-25days |
| Payment Terms: | T/T , paypal , Western Union, L/C |
| Supply Ability: | 100000pcs/month |
| Model No.: | JKBLD480 | Supply Voltage: | 24VDC - 48VDC |
|---|---|---|---|
| Current: | 0A - 10A | Weight: | 600g |
| Certified: | CE ROHS | Matched Motor: | 0 - 480w |
| Highlight: | 480w Brushless DC motor Driver,direct current Brushless DC motor Driver,Fast Response brushless dc driver |
||
24V~48VDC 0A-10A Brushless Dc Motor Driver JKBLD480 For 0-480w Bldc Motor
Description:
JKBLD480brushless DC motor driver is our company's latest high-tech product for the field of medium power motor drive. This product uses a large-scale integrated circuit to replace the original hardware. It has higher anti-jamming and fast response ability. It is suitable for all the three-phase brushless DC motors with low voltage DC18V-50V(boards show DC24V-48V) and peak current below 10A. Even if working with large current, it is still in low temperature. It is widely used in knitting equipment, medical equipment, food packaging machinery, power tools and a series of areas of electrical automation and control.
Electrical Specification:
(1)Environmental Temperature:25℃
| Power supply | DC18V～50V direct current (Capacity according to motor power selection) |
| The maximum input current | Not greater than10A (according to motor and rated load) |
| The maximum power | The maximum is 480W (over power motor is strictly prohibited) |
| Insulation resistance | General temperature﹥500MΩ |
| Insulation strength | General temperature and pressure 0.5KV,1minitute |
(2)EnvironmentalParameter
| Cooling method | Natural air cooling (forced air cooling is recommended) | |
| Environment | Condition | Avoid dust, oil mist and corrosive gases |
| Temperature | 0℃～+50℃ | |
| Humidity | ﹤80%RH,no condensation, no frost | |
| Vibration | ﹤0.5G(4.9m/s2 )10Hz-60Hz (non-continuous operation) | |
| Reserved temperature | -20℃～+65℃ | |
| Size | 118mmX75.5mmX34mm | |
| Weight | About 0.3Kg | |
Main features:
It can be connected with an external speed display board, showing the speed; it can also be connected with computers to set drive parametersIt has double speed closed current design with low speed torque and smooth operation;
It has high speed output with the maximum speed of 20000rpm / min;
Speed control mode : analog quantity 0-5V,(according to the users’ requirement we can set PWM within 10Hz-300Hz
It has have EN, DIR signal control side;
It can output tachometer pulse;
It has over-current, overvoltage, under voltage , overheating, motor stalling and other protection functions
