ROHS Cnc Router Microstep TB6600 Stepper Motor Driver Controller Kit

ROHS Cnc Router Microstep TB6600 Stepper Motor Driver Controller Kit

  • ROHS Cnc Router Microstep  TB6600 Stepper Motor Driver  Controller Kit
  • ROHS Cnc Router Microstep  TB6600 Stepper Motor Driver  Controller Kit
ROHS Cnc Router Microstep  TB6600 Stepper Motor Driver  Controller Kit
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jkongmotor
Certification: CE, ROHS,ISO9001
Model Number: TB6600 , 4 Axis Breakout Board
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/Pieces
Price: US $28 - 32 / Pieces
Packaging Details: with export carton . big quantity with pallet
Delivery Time: For samples , 7-15 days / For batch , 15-25days
Payment Terms: T/T , paypal , Western Union, L/C
Supply Ability: 30000 pcs/month
Contact Now
Detailed Product Description
Type: Breakout Board Current Range: 0.8A-4.5A
Power Supply Voltage: 18 - 40V Weight: 600g
Matched Motor: Nema23 Stepper Motor Certified: CE ROHS
High Light:

Cnc Router tb6600 stepper motor driver

,

ROHS tb6600 stepper motor driver

,

ROHS tb6600 microstep driver



CNC Kit TB6600 Stepper Motor Driver TB6600 3 Axis Controller


Product Description:
1. Hardware Features
  • Hardware Features
  • Supports MACH3, KCAM4, EMC2 etc…
  • Can drive four channels 4.5A stepper motors, input voltage up to 18V - 40V.
  • Resolution 1, 1/2, 1/4, 1/8, 1/16 micro stepping output.
  • 100% Full DC-DC high-speed optical isolation to protect the user's computer and equipment.
  • Four channels of 0.4 - 4.5A adjustable output current for 2/4 phase bipolar stepper driver.
  • Build with 1 ways relay output and 5 ways limit interface.
  • Automatic idle-current reduction.



Pins define:



LPT pins Pin symbols Functions
1 PWM 0-10V output control
2 STEPX X axis pulse
3 DIRX X axis direction
4 STEPY Y axis pulse
5 DIRY Y axis direction
6 STEPZ Z axis pulse
7 DIRZ Z axis direction
8 STEPC C axis pulse
9 DIRA C axis direction
10 LIMIT-1 LPT input signal 1
11 LIMIT-2 LPT input signal 2
12 LIMIT-3 LPT input signal 3
13 LIMIT-4 LPT input signal 4
14 ENABLE_ALL All axis enable input
15 LIMIT-5 LPT input signal 5
16   NO USE
17 RELAY Relay control
18-25 GND Common GND for PC
