Hybrid 80mN.M 42ZYT 2 Phase 14W Nema 17 Brushed Servo Motor

Hybrid 80mN.M 42ZYT 2 Phase 14W Nema 17 Brushed Servo Motor

  • Hybrid 80mN.M  42ZYT  2 Phase 14W  Nema 17  Brushed Servo Motor
Hybrid 80mN.M  42ZYT  2 Phase 14W  Nema 17  Brushed Servo Motor
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jkongmotor
Certification: CE, ROHS,ISO9001
Model Number: 42ZYT01A
Payment & Shipping Terms:
Minimum Order Quantity: 3 - 5 Unit/Units
Price: US $11 - 31 / Units | 3 Unit/Units (Min. Order)
Packaging Details: with export carton . big quantity with pallet
Delivery Time: For samples , 7-15 days / For batch , 15-25days
Payment Terms: T/T , paypal , Western Union, L/C
Supply Ability: 30000 pcs/month
Contact Now
Detailed Product Description
Phase: 2 Type: Hybrid
Step Angle: 1.8 Degree Holding Torque: 80mN.M
Speed: 3500rpm Weight: 390g
High Light:

Nema 17 brushed servo motor

,

2 Phase brushed servo motor

,

Nema 17 brushed dc motor


42ZYT Series Dc Brush Motor Nema17 80mN.m Rated Torque Output Power 14W


The basic construction of a DC brush motor consists of the stator, rotor, brush and commutator. The stator and rotor magnetic fields interact to drive the motor. The types of BRUShless DC motors are classified according to the way the magnetic fields are generated in the stator or casing of the motor. Depending on the type of brushless DC motor, the stator magnetic field may be generated by permanent magnets or windings in the stator. In the latter case, the stator windings and the rotor windings may be connected in parallel, serial, or mixed modes. These three kinds of brushless DC motors are called shunt motor, series motor and complex motor respectively.



Detailed Product Description:

  • voltage, 12v, 24v, 36v, 40v

  • rated speed, 3500rpm

  • rated torque, 38mNm

  • power 15w~20w

  • O.D 42mm, length 70mm

  • 42ZYT01A, 14W



Motor Specifications

  • High quality ball bearing
  • Hard ferrite magnet, 2- poles
  • Protection class IP50
  • Insulation class: F
  • Certified by CE and ROHS



Model 42ZYT01A
Voltage V 24
No load speed rpm 4200
Rated torque mNm 38
Rated speed rpm 3500
Weight Kg 0.39
L1 mm 70
Power W 14



Hybrid 80mN.M  42ZYT  2 Phase 14W  Nema 17  Brushed Servo Motor 0Hybrid 80mN.M  42ZYT  2 Phase 14W  Nema 17  Brushed Servo Motor 1



Black Nema 17 Motor 100m.Nm 4700rpm Output Power 49W Voltage 6V - 60V 2



The stator generates a stationary magnetic field.This stationary magnetic field surrounds the armature, or rotor. The external power source excites the armature magnetic field. Dc brush motor motor shaft there are two circular arc copper, known as the commutator. As the motor turns, the carbon brushes slide on the commutator. This produces a rotating magnetic field attracted to the stator's stationary magnetic field. The current in the armature and stator windings is supplied by the battery or other DC power supply (permanent magnet DC brushless MOTOR has no stator windings). A battery (or DC power supply) provides a constant DC voltage. The voltage amplitude determines the speed of the motor, so the battery or DC power supply is a linear excitation source. Pulse width modulation (PWM) is the most effective way to change the speed of brushless DC motor. PWM technology is a constant voltage source with fixed frequency switch. The speed of motor can be adjusted by changing the pulse width of PWM signal. The ratio between high and low pulse levels is called PWM signal duty ratio. The amplitude of the DC battery level is equal to the average amplitude of the PWM signal.



Application

A dc motor has a good starting and speed control performance, often used in the occasion of starting and speed regulation have higher requirements, such as a large reversible rolling mill, mine hoist, the hotel high-speed elevators, planing machine, electric locomotives, diesel locomotive, city tram, subway trains, electric bicycle, papermaking and printing machinery, ship machinery, large precision machine tools and large crane and other production machinery.
