| Place of Origin: | Jiangsu, China (Mainland) |
| Brand Name: | JK |
| Certification: | CE, ROHS,ISO9001 |
| Model Number: | iHSS60-36-30-31 |
| Minimum Order Quantity: | 3-10pcs |
|---|---|
| Price: | USD60-75 |
| Packaging Details: | with export carton . big quantity with pallet |
| Delivery Time: | For samples , 7-15 days / For batch , 15-35days |
| Payment Terms: | T/T, Western Union, paypal, L/C |
| Supply Ability: | 100000pcs/month |
| Product Name: | Integrated Closed Loop Stepper Motor | Model Name: | IHSS60-36-30-31 |
|---|---|---|---|
| Postion Accuracy: | 1.8°±0.09 | Temp Rise( Max): | 80°C |
| Dielectric Strength: | 500VDC | Insulation Class: | B |
| Current /phase: | 5.0A | DC Resistance: | 0.43Ω |
| Inductance /phase: | 2.0mH | Holding Torque: | 3.0Nm |
| High Light: | Nema24 Closed Loop Stepper Motor,5A Closed Loop Stepper Motor,Stepper Motor With Integrated Driver |
||
Black body 1.8deg 5A 3N.m Nema24 closed loop Stepper Motor with Integrated driver
Stepping systems combine high-performance microstepping drives with high-torque stepper motors to provide simple and accurate control of position and velocity where open or closed-loop control is desired and cost is a factor.
• Standard and Advanced Drives and Integrated Motor/Drives can accept high-speed pulse input control.
• Advanced Drives and some Integrated Motor/Drives can also accept serial communication control.
Specification of Nema24 closed loop stepper motor with integrated driver:
| Brand | Jkongmotor |
| Name | Integrated Close Loop Stepper Motor |
| Model Name | iHSS60-36-30-31 |
| Step Angle | 1.8° |
| Postion accuracy | 1.8°±0.09 |
| Number of phase | 2 |
| Temp rise( Max) | 80°C |
| Dielectric Strength | 500VDC |
| Insulation Class | B |
| Current /phase | 5.0A |
| DC Resistance | 0.43Ω |
| Inductance /phase | 2.0mH |
| Holding torque | 3.0Nm |
| Inertria | 690g.cm² |
Other models available:
| Model Name: | Holding Torque: | Voltage: | Current: | Shaft Size: | D-cut Size: | Body Length: |
| iHSS42-24-05 | 0.48N.m | 24V | 1.2A | 5*24mm | 15mm | 76mm |
| iHSS42-24-07 | 0.7N.m | 24V | 1.2A | 5*24mm | 15mm | 88mm |
| iHSS57-36-10 | 1.2N.m | 36V | 4.0A | 8*21mm | 15mm | 108mm |
| iHSS57-36-20 | 2N.m | 36V | 5.0A | 8*21mm | 15mm | 127mm |
| iHSS60-36-30 | 3N.m | 60V | 5.0A | 8*31mm | 25mm | 117mm |
| iHSS86-60-45 | 4.5N.m | 60V | 6.0A | 14*38mm | 73mm | 121mm |
| iHSS86-80-85 | 8.5N.m | 80V | 6.0A | 8*21mm | 73mm | 141mm |
Photos of iHSS60-36-30-31:
Motor features:
* Integrated compact size for saving mounting space
* Without losing step, High accuracy in positioning
* 100% rated output torque
* Variable current control technology, High current efficiency
* Small vibration, Smooth and reliable moving at low speed
* Accelerate and decelerate control inside, Great improvement in smoothness of starting or stopping the motor
* User-defined micro steps
* No adjustment in general applications
* Over current, over voltage and over position error protection
* Green light means running while red light means protection or off line
Changzhou Jkongmotor Co., Ltd was a high technology industry zone in changzhou, china. Our products used in many kinds of machines, such as 3d printer CNC machine, medical equipment, weaving printing equipments and so on.JKONGMOTOR warmly welcome 'OEM' & 'ODM' cooperations and other companies to establish long-term cooperation with us.
Company spirit of sincere and good reputation, won the recognition and support of the broad masses of customers, at the same time with the domestic and foreign suppliers close community of interests, the company entered the stage of stage of benign development, laying a solid foundation for the strategic goal of realizing only really the sustainable development of the company.
