Integrated Closed Loop Stepper Motor 1.8° 36v Typical 3.0N.M Body Length 117mm

Integrated Closed Loop Stepper Motor 1.8° 36v Typical 3.0N.M Body Length 117mm

Integrated Closed Loop Stepper Motor 1.8° 36v Typical 3.0N.M Body Length 117mm
video
Integrated Closed Loop Stepper Motor 1.8° 36v Typical 3.0N.M Body Length 117mm
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: JK
Certification: CE, ROHS,ISO9001
Model Number: iHSS60-36-30-31
Payment & Shipping Terms:
Minimum Order Quantity: 3-10pcs
Price: USD60-75
Packaging Details: with export carton . big quantity with pallet
Delivery Time: For samples , 7-15 days / For batch , 15-35days
Payment Terms: T/T, Western Union, paypal, L/C
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Product Name: Integrated Closed Loop Stepper Motor Model Name: IHSS60-36-30-31
Step Angle: 1.8° Postion Accuracy: 1.8°±0.09
Number Of Phase: 2 Temp Rise( Max): 80°C
Dielectric Strength: 500VDC Insulation Class: B
Current /phase: 5.0A DC Resistance: 0.43Ω
Inductance /phase: 2.0mH Holding Torque: 3.0Nm
High Light:

117mm Integrated Closed Loop Stepper Motor

,

36v Closed Loop Stepper Motor

,

iHSS60-36-30-31

1.8° 36v typical 3.0N.m body length 117mm Integrated closed loop Stepper Motor



The Integrate Stepper Servo Motor is merged the stepper servo driver and motor together. This motor system integrates the servo control technology into the digital stepper drive perfectly. And this product adopts an optical encoder with high speed position sampling feedback of 50 μ s, once the position deviation appears, it will be fixed immediately. This product is compatible the advantages of the stepper drive and the servo drive, such as lower heat, less vibration, fast acceleration, and so on.



Details parameters of Integrated Close Loop Stepper Motor:

  • Brand: Jkongmotor
  • Name: Integrated Close Loop Stepper Motor
  • Model Name: iHSS60-36-30-31
  • Step Angle: 1.8°
  • Postion accuracy: 1.8°±0.09
  • Number of phase: 2
  • Temp rise( Max): 80°C
  • Dielectric Strength: 500VDC
  • Insulation Class: B
  • Current /phase: 5.0A
  • DC Resistance: 0.43Ω
  • Inductance /phase: 2.0mH
  • Holding torque: 3.0Nm
  • Inertria: 690g.cm²


Specification of Nema24 closed loop stepper motor with integrated driver:



item value
Warranty 3months-1year
Place of Origin China
Brand Name jkongmotor
Model Number iHSS60-36-30-31
Phase 2
Type Hybrid
Current / Phase 5.0A
Certification ce, ISO, RoHS
Product name Integrated Close Loop Stepper Motor
Model name iHSS60-36-30-31
Voltage 36V
Holding Torque 3.0N.m
Step Angle 1.8degree
Shaft size 8*31mm
D-cut size 25mm
Body length 117mm
Keywords 60 Integrated Closed Loop Stepper Motor
Product Keywords nema 24 Integrated Dc Servo Motor





Photos of iHSS60-36-30-31:



Integrated Closed Loop Stepper Motor 1.8° 36v Typical 3.0N.M Body Length 117mm 0

Other models available:



Model Name: Holding Torque: Voltage: Current: Shaft Size: D-cut Size: Body Length:
iHSS42-24-05 0.48N.m 24V 1.2A 5*24mm 15mm 76mm
iHSS42-24-07 0.7N.m 24V 1.2A 5*24mm 15mm 88mm
iHSS57-36-10 1.2N.m 36V 4.0A 8*21mm 15mm 108mm
iHSS57-36-20 2N.m 36V 5.0A 8*21mm 15mm 127mm
iHSS60-36-30 3N.m 60V 5.0A 8*31mm 25mm 117mm
iHSS86-60-45 4.5N.m 60V 6.0A 14*38mm 73mm 121mm
iHSS86-80-85 8.5N.m 80V 6.0A 8*21mm 73mm 141mm





Motor features:



* Integrated compact size for saving mounting space
* Without losing step, High accuracy in positioning
* 100% rated output torque
* Variable current control technology, High current efficiency
* Small vibration, Smooth and reliable moving at low speed
* Accelerate and decelerate control inside, Great improvement in smoothness of starting or stopping the motor
* User-defined micro steps
* No adjustment in general applications
* Over current, over voltage and over position error protection
* Green light means running while red light means protection or off line

Integrated Closed Loop Stepper Motor 1.8° 36v Typical 3.0N.M Body Length 117mm 1

Integrated Closed Loop Stepper Motor 1.8° 36v Typical 3.0N.M Body Length 117mm 2Integrated Closed Loop Stepper Motor 1.8° 36v Typical 3.0N.M Body Length 117mm 3
