Name: 2Nm Nema34 Closed Loop Stepper Motor For CNC Machine JK86HSN120
Brand: Jkongmotor
SKU: JK86HSN120
Price: 78.5 USD
Availability: InStock
Rating: 5 (138 reviews)

Home Products Closed Loop Stepper Motor

2Nm Nema34 Closed Loop Stepper Motor For CNC Machine JK86HSN120

Product Details:

Place of Origin:	Jiangsu, China (Mainland)
Brand Name:	Jkongmotor
Certification:	CE, ROHS,ISO9001
Model Number:	JK86HSN120

Payment & Shipping Terms:

Minimum Order Quantity:	3-10pcs
Price:	US$78.5~US$93.5
Packaging Details:	with export carton . big quantity with pallet
Delivery Time:	For samples , 7-15 days / For batch , 15-25days
Payment Terms:	T/T , paypal , Western Union, L/C
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Type:	Closed Loop	Phase:	2
No Of Leads:	4	Shaft:	14mm Keyway Shaft
Keyway Height:	16mm	Current:	6.0A
Holding Torque:	12N.m	Stock:	Yes
Usage:	CNC Router	Voltage:	2.6V
High Light:	2Nm CNC Closed Loop Motor , JK86HSN120 CNC machine Stepper Motor , 2Nm nema 34 bldc motor

12N.m Nema34 Closed loop Motor + driver full kit

1) Product Name: 12N.m Nema34 Closed loop servo stepper motor
Model: JK86HSN120
Number of Phase: 2
Step Angle: 1.8 Degree
No. of Leads: 4
Rated Voltage: 2.64V
Rated Current: 6.0 Amps
Holding Torque: 12N.m
Motor Diameter: 86mm
Motor length:183.5mm
Shaft Length: 37mm
Shaft Diameter: 14mm

2) Product Name: 12N.m Nema34 Closed loop servo stepper driver
Model:JK-HSD86
Voltage Range: 30-110VDC, 20-80VAC
Microstep/pulse: 51200/rev

3)Typical applications: CNC machine

2Nm Nema34 Closed Loop Stepper Motor For CNC Machine JK86HSN120 0

1. Genaral Specification of closed loop stepper motor:

Step Angle : 1.8°
Temperature Rise : 80℃max
Ambient Temperature : -20℃~+50℃
Insulation Resistance : 100 MΩ Min. ,500VDC
Dielectric Strength : 500VAC for 1minute
Shaft Radial Play : 0.02Max. (450g-load)
Shaft Axial Play : 0.08Max. (450g-load)
Max. radial force : 220N (20mm from the flange)
Max. axial force : 60N

2. Electrical Specification of nema34 stepper motor closed loop:

Model No.

Motor Length

Current

/Phase

Resistance

/Phase

Inductance

/Phase

Holding Torque

# of Leads

Detent Torque

Rotor Inertia

Mass

(L)mm

N.m

No.

Kg.cm

g.cm

JK86HSN120

155

0.44

3.8

3.6

4000

5.9

3. Matching Stepper motor Driver: JK-HSD86

JK-HSD86 is one of the models in Jkongmotor series easy servo drives which can take 20-80 VDC operating voltage and output 0.1 -10A continuous load-based current. It is capable of driving NEMA 17, 23, 24 and 34 easy servo motors (stepper motors with encoders) with the position loop closed in real time.
Based on latest DSP technology and adopting Novo's advanced control algorithm, JK-HSD86 easy servo drive applies servo control on easy servo motors. When adopted with an easy servo motor, it combines features of both open loop steppers & brushless servo systems, and offers many unique advances features for excellent motion control system performance.
When an JK-HSD86 easy servo drive is implemented with a novo SC series easy servo motor, there is No
Configuration Needed for almost all applications. The output resolution from JK-HSD86 with the output resolution defaulted to output resolution of 2,000 pulses per resolution (equal to 10 microstep in 2-phase stepper systems). Via DIP switches, a user can also easily change the output resolution to one of 15 output resolutions 400 to 51,200 (equal to 2-256 microstep in 2-phase stepper systems). With novo configuration software, ProTuner, an advanced user can also set custom settings of resolution, current & position loop parameters, idle current percentage, etc.

2Nm Nema34 Closed Loop Stepper Motor For CNC Machine JK86HSN120 1

4. Applications
With many unique advanced features, JK-HSD86 easy servo systems are ideal for many industries to
upgrade stepper performance or replace brushless servo systems in many applications.
Jkongmotor OEM clients have successfully implemented JK-HSD86 driven easy servo systems in applications such assmall-to-large size CNC routers, CNC mills, plasmas, large-scale laser cutters / engravers, labeling equipments,robotics, gemstone processing machines, pick & place machines, X-Y tables.

5. Drawing
2Nm Nema34 Closed Loop Stepper Motor For CNC Machine JK86HSN120 2

6.Our service
We do also manufacture other products,such as Nema8,nema11,nema14,nema16,nema17,nema23,nema24,nema34,nema42,nema52 stepper motor;
Nema11,nema17,nema23,nema24,nema34 stepper motor with gearbox.
Linear stepper motor,closed loop stepper motor,stepper motor with brake,stepper motor sriver;
42mm,57mm,60mm,80mm,86mm,110mm,130mm brushless dc motor;
Bldc motor with gearbox,bldc motor driver;
Brush dc motor,spindle motor,ac servo motor kit,couplings,pulley,power supply and so on.

Tag:

Contact Person: Miss. Annie

Tel: +8615995098661

Fax: 86-519-88713769
