| Place of Origin: | Jiangsu, China (Mainland) |
| Brand Name: | Jkongmotor |
| Certification: | CE, ROHS,ISO9001 |
| Model Number: | JK110BLS75 |
| Minimum Order Quantity: | 3-10pcs |
|---|---|
| Price: | US $80 - 110 / Pieces | 1 Piece/Pieces (Min. Order) |
| Packaging Details: | with export carton . big quantity with pallet |
| Delivery Time: | For samples , 7-15 days / For batch , 15-25days |
| Payment Terms: | T/T , paypal , Western Union, L/C |
| Supply Ability: | 30000PCS/MONTH |
| Product Name: | 110mm BLDC Motor | Speed: | 3000rpm |
|---|---|---|---|
| Rated Current: | 3.7A | Output Power: | 1030W |
| Voltage: | 310V | Body Length: | 155mm |
| Holding Torque: | 3.3N.m | Phase: | 3 |
| Pole: | 8 | Motor Diameter: | 110mm |
| Insulation Class: | Class F | Application: | Automation |
| High Light: | 310V three phase brushless motor,110mm three phase brushless motor,ROHS 1kw brushless dc motor |
||
3.3N.m Industrial 1KW 310V 110mm Three Phase Brushless Dc Motor
Product Description:
110mm brushless dc motor , BLDC MOTOR
310v dc brushless motor, 110mm dc brushless motor,
3000RPM DC brushless motor
Specification of 3000RPM high speed DC motor:
| Model | ||
| Specification | Unit | JK110BLS75 |
| Number Of Phase | Phase | 3 |
| Number Of Poles | Poles | 8 |
| Rated Voltage | VDC | 310 |
| Rated Speed | Rpm | 3000 |
| Rated Torque | N.m | 3.3 |
| Rated Current | Amps | 3.7 |
| Rated Power | W | 1030 |
What are brushless DC motors used for?
The most common uses of brushless DC motors in industrial engineering are linear motors, servomotors, actuators for industrial robots, extruder drive motors and feed drives for CNC machine tools.
Are brushless DC motors better?
Brushless Motor Advantages
Since brushless DC motors have no brushes to get worn out, they represent a huge leap forward in technology. Brushless motors have significantly higher efficiency and performance, and a lower susceptibility to mechanical wear than their brushed counterparts.
