| Place of Origin: | Jiangsu, China (Mainland) |
| Brand Name: | Jkongmotor |
| Certification: | CE, ROHS,ISO9001 |
| Model Number: | JK86BLS125 |
| Minimum Order Quantity: | 3-10pcs |
|---|---|
| Price: | US $48 - 70 / Pieces | 1 Piece/Pieces (Min. Order) |
| Packaging Details: | with export carton . big quantity with pallet |
| Delivery Time: | For samples , 7-15 days / For batch , 15-25days |
| Payment Terms: | T/T , paypal , Western Union, L/C |
| Supply Ability: | 30000PCS/MONTH |
| Torque: | 2.1N.m | Speed: | 3000rpm |
|---|---|---|---|
| Rated Current: | 18A | Output Power: | 660W |
| Voltage: | 48V -310V | Rotor Inertia: | 2400g.cm2 |
| MOQ: | 10pcs | ||
| High Light: | 86mm 3 Phase DC motor,48V 3 Phase DC motor,750W three phase brushless motor |
||
660W 750W 48V Brushless Dc Motor Bldc Motor High Speed 3000RPM
Product Description:
86mm brushless dc motor , BLDC MOTOR
48v dc brushless motor, 86mm dc brushless motor,
3000RPM DC brushless motor
Specification of 3000RPM high speed DC motor:
| Model | |||
| Specification | Unit | JK86BLS98 | JK86BLS125 |
| Number Of Phase | Phase | 3 | |
| Number Of Poles | Poles | 8 | |
| Rated Voltage | VDC | 48 | |
| Rated Speed | Rpm | 3000 | |
| Rated Torque | N.m | 1.4 | 2.1 |
| Rated Current | Amps | 11.5 | 18 |
| Rated Power | W | 440 | 660 |
We have more attractive price and shorter lead time.
