CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter

CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter

  • CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter
  • CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter
  • CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter
CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jkongmotor
Certification: CE, ROHS,ISO9001
Model Number: 700W ER11
Payment & Shipping Terms:
Minimum Order Quantity: 3-10pcs
Price: US$ 102~US$110
Packaging Details: with export carton . big quantity with pallet
Delivery Time: For samples , 7-15 days / For batch , 15-25days
Payment Terms: T/T , paypal , Western Union, L/C
Supply Ability: 3000 pcs/month
Contact Now
Detailed Product Description
Nema: Spindle Motor Power: 700w
Voltage: 110v / 220v Current: 7.3A/3.7A
Speed: 1-11000 R/min Holding Torque: 0.55N.m
Motor Length: 117mm Collet: ER11
Colling: Air Cooling
High Light:

110v air cooling spindle motor

,

ER11 spindle motor

,

ER11 CNC milling motor

Φ80 1.5KW ER16 Water Cooled CNC Spindle Motor & Inverter Kit 110V / 220V / 380V



 Brand JKONGMOTOR
Product Name: spindle motor Model: 0.7kw air cooled
Holding Torque: 0.55N.m Motor Length: 117mm
Voltage: 110V / 220V Current: 7.3A / 3.7A
Collet: ER11 Speed: 0-11000rpm
Phase: 3phase Colling: Air cooling
Product Name: BLDC driver Max power: 600w
Model: NBD600M1 Max speed: 12000r/min
Supply voltage: 110VAC / 220VAC Install dimension: 120x55mm



CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter 0



CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter 1



CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter 2



CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter 3

CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter 4



Spindle motor features:

1) Imported bearings with good quality, long working life.
2) Application: Milling,Engraving,Drilling in all kinds of CNC Router machine.
3) There are water cooling spindle , air cooling spindle and self cooling spindle for your choose.
4) Every spindle motor must be passed polishing process, Improve spindle concentricity to increase motor working life.



Provide:

1. water cooling:800w,1.5kw,2.2kw,3kw,4kw,3.2kw,4.5kw,5.5kw
2. air cooling: 800w,1.5kw,2.2kw.3.5kw,4.5kw,6kw,7.5kw




Accessories:
We also have spindle motor matching inverter(VFD), collet , gripper etc.

If you need other kinds of parts, please don't hesitate to contact us.







TIPS:

The spindle motor of woodworking engraving machine is an important component of woodworking engraving machine. The advantages and disadvantages of the spindle motor directly affect the processing speed and accuracy of the engraving machine. How to select high-quality spindle motor is very important. ATO summarizes the main points of woodworking engraving machine spindle selection for the reference of users:

  •  If we pursue the efficiency of woodworking engraving machine, we should not only have a high speed, but also a large amount of knives. For example, when processing solid wood, we need a spindle motor with a power of more than 3KW.

  • Whether the spindle motor of woodworking engraving machine adopts high-precision bearings or not, if it does not use high-precision bearings, the performance is that the spindle motor overheated after long-term high-speed rotation, which affects the service life of the spindle motor.

  • Whether the spindle of woodworking engraving machine rotates at different speeds, especially at high speeds, the sound is uniform and harmonious.

  • Whether the radial force of the principal axis of woodworking engraving machine is applied. The main reference is whether the material with hard texture can be cut at high speed. Some spindle motors can only cut hard materials at very low speed, otherwise the performance of the motor will be seriously lost, which will affect the accuracy of the spindle after a period of time, or even cause faults.

CNC Milling 700w ER11 110v Air Cooling Spindle Motor With Inverter 5
