130ST 2.6KW 10N.M 2500rpm Brushless Ac Servo Motor With Encoder

Product Details:

Place of Origin:	Jiangsu, China (Mainland)
Brand Name:	JK
Certification:	CE, ROHS,ISO9001
Model Number:	130ST-M10025

Payment & Shipping Terms:

Minimum Order Quantity:	3-10pcs
Price:	US$300~US$345
Packaging Details:	with export carton . big quantity with pallet
Delivery Time:	For samples , 7-15 days / For batch , 15-35days
Payment Terms:	T/T, Western Union, paypal
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Brand:	JK	Model:	130ST-M10025
Frame Size:	130mm	Holding Torque:	10N.m
Rated Power:	2.6KW	Rated Speed:	2500Rpm
Rated Voltage:	220V	Rated Current:	10A
High Light:	2500rpm brushless ac servo motor , 10A brushless ac servo motor , 10A ac servo spindle motor

130ST 2.6KW 10N.m 2500rpm Ac servo motor with encoder for plastic machines

Advantages of Servo Motors:

High efficiency.
High output power relative to their size.
More constant torque at higher speed.
Closed-loop control.
Quiet operation.
Highly reliable.
High ratio of torque to inertia.
High acceleration.

Specifications of 400w Ac servo motor:

Motor Type	130ST-M04025	130ST-M05025	130ST-M06025	130ST-M07725	130ST-M10010	130ST-M10015	130ST-M10025	130ST-M15015	130ST-M15025
Rated Power(KW)	1	1.3	1.5	2.0	1.0	1.5	2.6	2.3	3.8
Rated Voltage(V)	220	220	220	220	220	220	220	220	220
Rated Current(A)	4.0	5.0	6.0	7.5	4.5	6.0	10	9.5	13.5
Rated Speed(rpm)	2500	2500	2500	2500	1000	1500	2500	1500	2500
Rated Torque(N.m)	4	5.0	6	7.7	10	10	10	15	15
Peak Torque(N.m)	12	15	18	22	20	25	25	30	30
Voltage Constant(V/Krpm)	72	68	65	68	140	103	70	114	67
Torque Coefficient(N.m/A)	1.0	1.0	1.0	1.03	2.2	1.67	1.0	1.58	1.11
Rotor Inertia(Kg.㎡)	0.85×10^-4	1.06×10^-4	1.26×10^-4	1.53×10^-4	1.94×10^-4	1.94×10^-4	1.94×10^-4	2.77×10^-4	2.77×10^-4
Line-Line Resistance(Ω)	2.76	1.84	1.21	1.01	2.7	1.5	0.73	1.1	0.49
Line-Line Inductance(mH)	6.42	4.9	3.87	2.94	8.8	4.37	2.45	4.45	1.68
Electrical Time Constant(ms)	2.32	2.66	3.26	2.91	3.26	2.91	3.36	4.05	3.43
Weight(Kg)	6.2	6.6	7.4	8.3	10.2	10.2	9.8	12.6	11.7
Insulation Class	Class F

Drawing of Servo motor:

130ST 2.6KW 10N.M 2500rpm Brushless Ac Servo Motor With Encoder 0

130ST 2.6KW 10N.M 2500rpm Brushless Ac Servo Motor With Encoder 1

130ST 2.6KW 10N.M 2500rpm Brushless Ac Servo Motor With Encoder 2

Servo motor Features:

These are low weight devices.
It offers reliability as well as stability in operation.
There is not much noise generated at the time of operation.
It offers almost linear torque-speed characteristics.
As brushes and slip rings are not present here thus it reduces maintenance cost.

Applications of AC Servo motors:

Due to the various advantages offered by the AC servomotors, these majorly finds applications in the instruments that operate on servomechanism, in position controlling devices, computers. Along with this these also find applications in tracking systems, machine tools and robotics machinery.

130ST 2.6KW 10N.M 2500rpm Brushless Ac Servo Motor With Encoder 3

130ST 2.6KW 10N.M 2500rpm Brushless Ac Servo Motor With Encoder 4

130ST 2.6KW 10N.M 2500rpm Brushless Ac Servo Motor With Encoder 5
