High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router

High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router

High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router
video
High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jkongmotor
Certification: CE, ROHS,ISO9001
Model Number: JK42HS40-1704-13A
Payment & Shipping Terms:
Minimum Order Quantity: 3-10pcs
Price: US$3.85~US$5.5
Packaging Details: with export carton . big quantity with pallet
Delivery Time: For samples , 7-15 days / For batch , 15-25days
Payment Terms: T/T , paypal , Western Union, L/C
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Name: Hybrid Stepper Motor Leads: 4
Current: 1.7A Holding Torque: 4.2kg.cm
Step Angle: 1.8 Degree Weight: 0.28kg
Shaft: 5mm D-cut Shaft Voltage: 2.55V
Phase Resistance: 1.5Ω Phase Inductance: 2.3mH
High Light:

nema 17 40mm

,

nema 17 high torque

,

nema 17 stepper motor

Nema17 Hybrid Stepper Motor 17HS4401 High Torque 4.2kg.cm 1.7A 40mm length for CNC router



Stepper motor is known by its property to convert a train of input pulses into a precisely defined increment in the shaft position.

This is a high quality motor that can be used for a long time without stuck.

It has a quite stable performance during work and will not loss step.

Low noise and big torque, this is a great choice if you need a stepper motor.

Stepper motor can be widely used for 3D printer, CNC engraving machine, etc.



1.Electrical Specification of 17HS4401 stepper motor:

  • Model No. : JK42HS40-1704-13A
  • Step Angle : 1.8°
  • Motor Length : 40mm
  • Current/Phase : 1.7A
  • Resistance/Phase : 1.5Ω
  • Inductance/Phase : 2.3mh
  • Holding Torque : 4.2kg.cm
  • # of Leads : 4
  • Detent Torque :150g.cm
  • Rotor Inertia :54g.cm
  • Mass : 0.28kg

2.Genaral Specification of nema 17 stepper motor:

Item Specifications
Step Angle 1.8°
Step Angle Accuracy ±5%(full step,no load)
Resistance Accuracy ±10%
Inductance Accuracy ±20%
Temperature Rise 80℃max
Ambient Temperature -20℃~+50℃
Insulation Resistance 100 MΩ Min. ,500VDC
Dielectric Strength 500VAC for 1minute
Shaft Radial Play 0.02Max. (450g-load)
Shaft Axial Play 0.08Max. (450g-load)
Max. radial force 28N (20mm from the flange)
Max. axial force 10N



3.Drawing of 17HS4401:


High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router 0

Product Details of JK42HS40-1704-13A:



High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router 1

High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router 2

High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router 3



4.Advantages of Hybrid Stepper Motor

The advantages of the Hybrid Stepper Motor are as follows:-

  • Low cost for control achieved
  • High torque at startup and low speeds
  • Ruggedness
  • Simplicity of construction
  • Can operate in an open loop control system
  • Low maintenance
  • Less likely to stall or slip
  • Will work in any environment
  • Can be used in robotics in a wide scale.
  • High reliability
  • The rotation angle of the motor is proportional to the input pulse.
  • The motor has full torque at standstill (if the windings are energized)
  • Precise positioning and repeatability of movement since good stepper motors have an accuracy of 3–5% of a step and this error is non-cumulative from one step to the next.
  • Excellent response to starting/stopping/reversing.
  • Very reliable since there are no contact brushes in the motor. Therefore, the life of the motor is simply dependent on the life of the bearing.
  • The motors response to digital input pulses provides open-loop control, making the motor simpler and less costly to control.
  • It is possible to achieve very low-speed synchronous rotation with a load that is directly coupled to the shaft.
  • A wide range of rotational speeds can be realized as the speed is proportional to the frequency of the input pulses.

High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router 4

High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router 5

High Torque Nema17 17HS4401 Hybrid Stepper Motor 40mm 1.7 A 4.2kg.cm For CNC Router 6
